Properties

Product codeNN.3304
Hose length 1.2m
Inner Diameter 16mm
Sensor Type Ni120
Nordson 129575

High Flex Standard, 5/8" - DN16, Ni120 Nordson Compatible
1.2m / 16mm

NN.3304

pce

There are 9 variants of this article, view them here >

HM Heated Hose, Hi-Flex, Std RTD Ni120, Auto,
ID 5/8''x 4 ft - DN16 x 1.20 m

- Protection Cover : Polyamid Braided Cover
- Temperature Sensor : Ni120
- Electrical : 240 VAC - 290 W
- Unit Side : Ni120-12p Connector, Cable 2,00m
- Gun Side : Ni120-6s Connector, Cable 0,40m
- Max. Temp. & Pressure : 200 °C - 105 Bar
- Hydraulic Fittings : DKJ 1-1/16-12

Nordson Compatible : ProBlue, VersaBlue, DuraBlue, VersaDrum, VersaPail, DuraDrum, DuraPail, 130 & 190 Series FoamMelt

Links & downloads

Download productfiche

Variants

Filter 9 of 9 visible.

Product code	Hose length	Inner Diameter
NN.3302	HM Hose, Hi-Flex Auto, Ni120, 5/8''x 2ft, DN16 x 0.60m	0.6m	16mm
NN.3304	HM Hose, Hi-Flex Auto, Ni120, 5/8''x 4ft, DN16 x 1.20m	1.2m	16mm
NN.3306	HM Hose, Hi-Flex Auto, Ni120, 5/8''x 6ft, DN16 x 1.80m	1.8m	16mm
NN.3308	HM Hose, Hi-Flex Auto, Ni120, 5/8''x 8ft, DN16 x 2.40m	2.4m	16mm
NN.3310	HM Hose, Hi-Flex Auto, Ni120, 5/8''x 10ft, DN16 x 3.00m	3.0m	16mm
NN.3312	HM Hose, Hi-Flex Auto, Ni120, 5/8''x 12ft, DN16 x 3.60m	3.6m	16mm
NN.3316	HM Hose, Hi-Flex Auto, Ni120, 5/8''x 16ft, DN16 x 4.80m	4.8m	16mm
NN.3320	HM Hose, Hi-Flex Auto, Ni120, 5/8''x 20ft, DN16 x 6.00m	6.0m	16mm
NN.3324	HM Hose, Hi-Flex Auto, Ni120, 5/8''x 24ft, DN16 x 7.40m	7.2m	16mm
